ESXI PASSTHROUGH GPU WIFI USB PRETTY

  • WARNING: NvmeScsi: 196: SCSI opcode 0x1a (0x457900ba2c40) on path vmhba4:C0:T0:L0 to namespace t10.NVMe failed with NVMe error status: 0x2
  • WARNING: translating to SCSI error H:0x0 D:0x2 P:0x0 Valid sense data: 0x5 0x24 0x0
  • WARNING: ScsiDeviceIO: 4422: ModeSense 0x1a request failed - blocking page:0x1c subpage:0x2 t10.NVMe
  • inter wifi won’t start
  • INTER AX200 / AX210 ESXI / PVE / UNRaid
  • WiFi Bluetooth
  • openwrt can’t find wlan
  • FAIL - Module ‘DevicePowerOn’ failed to power on.
  • ESXI Windows inter WiFi not work
  • ESXI Windows AMD GPU not work
  • ESXI virtual machine fails to boot after reboot (AMD GPU)
  • ESXI cannot start the virtual machine
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
scp ~/.ssh/authorized_keys esxi:/etc/ssh/keys-root/authorized_keys
ssh esxi "echo 'ChallengeResponseAuthentication no' >> /etc/ssh/sshd_config"
ssh esxi "echo 'PasswordAuthentication no' >> /etc/ssh/sshd_config"

### GPU
ssh esxi "lspci -v | grep -iA 1 Display"
ssh esxi "echo '1002  731f  bridge   false' >> /etc/vmware/passthru.map"
ssh esxi "echo '1002  731f  link     false' >> /etc/vmware/passthru.map"
ssh esxi "echo '1002  731f  d3d0     false' >> /etc/vmware/passthru.map"
ssh esxi "echo '/device/0000:05:00.0/owner = \"passthru\"' >> /etc/vmware/esx.conf"
### GPU END

### USB
ssh esxi "lsusb"
ssh esxi "echo 'usb.generic.allowHID = \"TRUE\"' >> /etc/vmware/config"
ssh esxi "echo 'usb.quirks.device0 = \"0x046d:0xc52b allow\"' >> /etc/vmware/config"
echo '"kernelopt=autoPartition=FALSE CONFIG./USB/quirks=0x046d:0xc52b::0xffff:UQ_KBD_IGNORE" : /bootbank/boot.cfg'
### USB END

# WIFI
echo '一般情况 WiFi 带蓝牙 注意直通 USB 蓝牙'
ssh esxi "lspci | grep Network"
ssh esxi "echo '8086  2725  bridge   false' >> /etc/vmware/passthru.map"
ssh esxi "echo '8086  2725  link     false' >> /etc/vmware/passthru.map"
ssh esxi "echo '8086  2725  d3d0     false' >> /etc/vmware/passthru.map"
ssh esxi "echo '/device/0000:0a:00.0/owner = \"passthru\"' >> /etc/vmware/esx.conf"

ssh esxi "lsusb -v | grep -i Bluetooth | grep Bus"
ssh esxi "echo 'usb.quirks.device1 = \"0x8087:0x0032 allow\"' >> /etc/vmware/config"
echo '"kernelopt=autoPartition=FALSE CONFIG./USB/quirks=0x046d:0xc52b::0xffff:UQ_KBD_IGNORE:0x8087:0x0032::0xffff:UQ_KBD_IGNORE" : /bootbank/boot.cfg'
### WIFI END

### Update
echo 'esxcli software vib install -d $PWD/nvme-community-driver_1.0.1.0-3vmw.700.1.0.15843807-component-18902434.zip'
echo 'esxcli software vib install -v $PWD/nvme.vib'
echo 'esxcli software sources profile list -d $PWD/VMware-ESXi-8.0a-20842819-depot.zip'
echo 'esxcli software profile update -d $PWD/VMware-ESXi-8.0a-20842819-depot.zip -p ESXi-8.0a-20842819-standard'
echo 'vmkfstools -i OpenWrt1.vmdk -d thin OpenWrt.vmdk'
echo 'vmkfstools -K OpenWrt.vmd'
### Update END

### Windows
echo 'hypervisor.cpuid.v0:FALSE'
echo 'pciPassthru0.msiEnabled : FALSE'
echo 'pciPassthru1.msiEnabled : FALSE'
echo 'pciPassthru.64bitMMIOSizeGB : 16'
echo 'pciPassthru.use64bitMMIO : TRUE'
### Windows END

### macOS
echo 'pciPassthru0.msiEnabled : FALSE'
echo 'pciPassthru1.msiEnabled : FALSE'
echo 'pciPassthru.64bitMMIOSizeGB : 16'
echo 'pciPassthru.use64bitMMIO : TRUE'
echo 'smbios.reflectHost : FALSE'
echo 'hw.model.reflectHost : FALSE'
echo 'board-id.reflectHost : FALSE'
echo 'serialNumber.reflectHost : FALSE'
echo 'smbios.use12CharSerialNumber : TRUE'
echo 'hw.model : MacPro7,1'
echo 'serialNumber : F5KZR05YP7QM'
echo 'board-id : Mac-27AD2F918AE68F61'
### macOS END

### OpenWrt
echo 'hypervisor.cpuid.v0:FALSE'
echo 'pciPassthru0.msiEnabled : FALSE'
echo 'pciPassthru.64bitMMIOSizeGB : 16'
echo 'pciPassthru.use64bitMMIO : TRUE'
echo 'vmkernel.boot.disableACScheck : TRUE'
### OpenWrt END

rm -rf /tmp/*.txt
rm -f /var/log/*.log
